Kverneland 3400 B VARIOMAT

The New generation shearbolt model Kverneland 3400 B Variomat® is designed for a peace of mind: high performances via a simple set-up, unbeatable low cost of ownership, unmatched robustness. The Trailer Transport Solution “TTS” offers the optimum maneuverability during transport. In-furrow to On-land is easily achieved in 2 simple steps. The pulling line adjusts automatically for the correct alignment at any time (Kverneland Auto-line). Combined with the renowned low draft Kverneland bodies, the fuel consumption is kept to its minimum while the lifetime of parts is extended beyond expectations. The adjustable “4P” skimmers enable the perfect ploughing. Shearbolts fitted to new robust legs shear sharp under 5 ton of pressure to guarantee a quality ploughing.

The Kverneland 3400 B Variomat® offers comfort with lower lift requirements than other brands. The headstock No 300 provides the necessary strength for a smooth reversing. Robust frame 120 x 200 mm. In its on-land configuration, the plough’s impressive offset (up to 3,85 m) allows the tractor to be positioned exactly to the drivers’ requirements.

The peace of mind is also illustrated with the unique wheel memory system that maintains the desired furrow depth settings after the reversing cycle. Likewise, one can choose an automatic front furrow adjustment instead of the standard mechanical solution.

Efficient re-consolidation in one pass: Kverneland packers and packer arm compatible.

• Easy swap from In-furrow to On-land operations. The driver has fingertip control
• Smooth turnover action thanks to an efficient parallel linkage system which hydraulically moves the plough into a balanced position
• Ideal for tractors having dual wheels or rubber track
• "4P" skimmers enabling easy adjustments in 4 Positions. For ex. quick working depth central adjustment.
• Optional automatic front furrow adjustment. Mechanical front furrow adjustment is standard
• Unique wheel memory system that maintains the desired furrow depth settings after the reversing cycle
• Safe transport: Kverneland Trailer Transport Solution (optional)
• Efficient re-consolidation in one pass. Kverneland packers and packer arm compatible
