Kverneland FRD
Versatility combined with efficiency
Versatile machine for front and rear tractor mounting
Highlights
For tractors up to 160hp Front and rear tractor mounting Easy operation in the field by hydraulic offset High-performance rotor for high-quality cutting Low maintenance costsDescription
The FRD is a versatile machine suitable for front and rear tractor mounting. The headstock is taken from the well-known and proven power harrow design. The sliding tube is integrated into the headstock; all forces and stress are concentrated on the 3-point linkage. The FRD is fitted as standard with a hydraulic-operated offset facility of 52cm. A central gearbox rated up to 160 hp with the double integrated freewheel is standard. The PTO tractor input can be 540 or 1000rpm, achieved by inverting the belt pulleys. Five V-belts combined with an automatic belt tensioner ensure smooth transmission, preventing slippage even in the toughest working conditions. No maintenance is required.
Features
- Versatile for use; front, rear, and offset ability, for tractors up to 160 hp
- Offset Frame: Machined post-welding for precise alignment.
- Double Headstock: Mounts at both front and rear.
- PTO tractor input at 540rpm or 1000rpm
- Central gearbox up to 160 hp
- Efficient rotor transmission with 5 V-belts and the BTS automatic belt tensioning system
- Strong Construction: Designed for reliability in demanding conditions.
- Wheel kit for front use with Ø 580mm
- A second counter knife is available as an option
- A double skin can be bolted in case of harsh working conditions (option)
Technical specifications
Technical specifications
Download brochureFRD | FRD | ||
---|---|---|---|
Working width (cm) | 280 | 320 | |
Transport width (cm) | 300 | 345 | |
No.of blades (univ /hammer) | 72/36 | 80/40 | |
Weight (kg) | 1220 | 1380 |
Multipurpose choppers
Technical specifications
Technical specifications
Download brochureModel |
Working Width (cm) |
Weight (kg) |
No. of universal/hammer blades |
FRD 280 |
280 |
1220 |
72/36 |
FRD 320 |
320 |
1380 |
80/40 |
