Kverneland CLC Evo – CLC Evo wings

The new 2-bar generation of the CLC is getting all the new recently designed innovation from the CLC pro 3-bar range.

It is now able to work with high HP tractors up to 350 hp, and is getting the full range of accessories available to optimise incorporation and levelling. The CLC Evo is extremely versatile from shallow cultivation of 7 cm down to loosening at 40cm deep. Available from 2.5m up to 4.9m, the CLC tines are providing the best crumbling by creating smaller aggregates, encouraging an easy incorporation of the residues with the disc gangs behind.

CLC Evo Wings

The Kverneland CLC Evo Wings is equipped with wing shares of 440mm. This ensures an extremely shallow cultivation (5cm) on the full working width.

The Advantages:

870mm underbeam clearance and 280mm average tine spacing for blockage-free operation
Breaks up soil compaction and plough pans to depths of 40cm
Tine designed to guarantee penetration even in extreme conditions
Flexible maintenance-free tines, providing high vibration through the ground for cracking and crumbling
2-bar frame compact cultivator to match with low tractor power
Stubble cultivation at 5cm now possible with CLC Evo Wings variant, with intermediate spacing of 420 or 370mm (fold) for efficient deep working without wings when necessary

Model	Working width (m)	No. of tines EVO/ No. of tines EVO wings	Min / Max HP
CLC Evo 250	2.5	9 / -	65 / 210
CLC Evo 300	3.0	11 / 7	80 / 240
CLC Evo 350	3.5	13 / 9	95 / 270
