The tasks of modern soil preparation are multifunctional. Additionally farmers have to meet their specific needs which are predetermined by location and farming practices.
The equipment possibilities of the Kverneland CTC are as versatile as your demands, with a choice of different implement combinations and variants Kverneland offer the possibility to equip the CTC to meet your individual needs.
The Kverneland CTC offers total flexibility with:
- 3 tine spacings
- 2 tine variants
- 8 types of shares
- 2 types of front cutting discs
- 4 types of levelling devices
- 3 types of rear roller
The CTC can be equipped with 3 rows of tines positioned at either 270mm or 330mm spacing.
When fitted with four rows of tines the tine distance is 200mm.
| Model | No. of tines | No. of rows | Min./Max. HP |
| CTC 400 / 4.0m |
11 (spacing 330mm) / 3.7m 15 (spacing 270mm) / 4.0m 19 (spacing 200 mm) / 3.8m |
3 (spacing 270 or 330mm) or 4 (spacing 200mm) | 145 / 280 |
| CTC 500 / 5.0m |
15 (spacing 330mm) / 5.0m 17 (spacing 270mm) / 4.6m 23 (spacing 200mm) / 4.6m |
3 (spacing 270 or 330mm) or 4 (spacing 200mm) | 175 / 320 |
| CTC 600 / 6.0m |
17 (spacing 330mm) / 5.7m 21 (spacing 270mm) / 5.7m 29 (spacing 200mm) / 5.8m |
3 (spacing 270 or 330mm) or 4 (spacing 200mm) | 205 / 360 |
